APPLICATIONS
Premium outdoor luminaire suitable for parking areas, auto dealerships, industrial yards, building exteriors, roadways, alleys, and pedestrian walkways.
FEATURES/MATERIALS/STRUCTURES
Construction
Manufactured for weather-proof durability using solid heavy duty die cast aluminum housing with anti-UV polyester coating to resist water, salt, corrosion, discoloration, and scratching. IP65 Wet Location rated for dust-tight, water-jets: IEC 60529. Vibration Acceleration Rating 3g: IEC 6008-2-6:1995.
Electrical
Input voltages 120-277V or 3477-480V models with 0-10V Continuous Dimming. Operating temperatures -40F° to 113 °F (-40°C to 45°C). Twist- lock top photocell sensor. Shorting Cap for manual switch or timer control.
Mounting
Adjustable options include Slip-Fit, Round /Square Pole, Trunnion Mount, and Straight-Arm Wall Mount.
Optics
Anti-UV Clear Polycarbonate IES / NEMA Type III Lens standard. Type IV and Type V Lens available.
Controls
PIR Photocell Twist-Lock Top, integrated Microwave Bi-Level Dimming and Motion Detection sensor with Remote Control. Shorting Cap for manual switch or timer control.
Listings
UL certified to meet US and Canadian standards. FCC, CE and RoHS compliant. Listed to qualify for energy-efficient LED lighting rebates.
Warranty
5 yr /50K hrs.
